Class 11 Physics Practicals —
Class 11 Physics Practicals —
Section A & B, Experiments + Activities
Poora CBSE practical syllabus ek hi page par — Section A (measurement aur mechanics: vernier callipers, screw gauge, spherometer, simple pendulum) aur Section B (properties of matter, heat aur waves: Young's modulus, surface tension, viscosity, cooling curve, sonometer). Har item ka Aim, procedure, observation table, graph aur result. Card par click karo, practical seedha khul jayega.
25Total Items
18Experiments
7Activities
11Chapters
📈 Aapki Practical Progress
0 / 25 complete — tick karte jaiye, browser me save ho jayega.
25 practicals & activities dikh rahe hain
A
Section A — Measurement & Mechanics
Units and Measurements · Motion in a Plane · Oscillations · Laws of Motion · Work, Energy & Power · Rotational Motion
8 Experiments7 Activities
🧪 Section A — Experiments
PracticalA-2📏 Units & Measurements
AimTo Measure the Diameter of a Given Wire and the Thickness of a Given Sheet Using a Screw Gauge
CBSE · Class 11 · English · Section A Experiment
A-3📏 Units & Measurements
AimTo Determine the Volume of an Irregular Lamina Using a Screw Gauge
CBSE · Class 11 · English · Section A Experiment
A-4📏 Units & Measurements
AimTo Determine the Radius of Curvature of a Given Spherical Surface by a Spherometer
CBSE · Class 11 · English · Section A Experiment
A-5📏 Units & Measurements
AimTo Determine the Mass of Two Different Objects Using a Beam Balance
CBSE · Class 11 · English · Section A Experiment
A-6🎯 Motion in a Plane
AimTo Find the Weight of a Given Body Using the Parallelogram Law of Vectors
CBSE · Class 11 · English · Section A Experiment
A-7⏱️ Oscillations
AimUsing a Simple Pendulum to Plot L–T and L–T² Graphs and Find the Effective Length of a Second's Pendulum
CBSE · Class 11 · English · Section A Experiment
A-8⏱️ Oscillations
AimTo Study the Variation of Time Period of a Simple Pendulum with Bobs of Same Size but Different Masses
CBSE · Class 11 · English · Section A Experiment
🔧 Section A — Activities
ActivityA-1📏 Units & Measurements
AimTo Make a Paper Scale of Given Least Count, e.g. 0.2 cm and 0.5 cm
CBSE · Class 11 · English · Section A Activity
A-2⚖️ Rotational Motion
AimTo Determine the Mass of a Given Body Using a Metre Scale by the Principle of Moments
CBSE · Class 11 · English · Section A Activity
A-3📏 Units & Measurements
AimTo Plot a Graph for a Given Set of Data, with Proper Choice of Scales and Error Bars
CBSE · Class 11 · English · Section A Activity
A-4🛞 Laws of Motion
AimTo Measure the Force of Limiting Friction for Rolling of a Roller on a Horizontal Plane
CBSE · Class 11 · English · Section A Activity
A-5🎯 Motion in a Plane
AimTo Study the Variation in Range of a Projectile with Angle of Projection
CBSE · Class 11 · English · Section A Activity
A-6🔋 Work, Energy & Power
AimTo Study the Conservation of Energy of a Ball Rolling Down an Inclined Plane, Using a Double Inclined Plane
CBSE · Class 11 · English · Section A Activity
A-7⏱️ Oscillations
AimTo Study Dissipation of Energy of a Simple Pendulum by Plotting a Graph Between Square of Amplitude and Time
CBSE · Class 11 · English · Section A Activity
B
Section B — Properties of Matter, Heat & Waves
Mechanical Properties of Solids & Fluids · Kinetic Theory · Thermal Properties of Matter · Waves
10 Experiments
🧪 Section B — Experiments
PracticalB-1🧵 Mechanical Properties of Solids
AimTo Determine Young's Modulus of Elasticity of the Material of a Given Wire
CBSE · Class 11 · English · Section B Experiment
B-2🧵 Mechanical Properties of Solids
AimTo Find the Force Constant of a Helical Spring by Plotting a Graph Between Load and Extension
CBSE · Class 11 · English · Section B Experiment
B-3🎈 Kinetic Theory / Thermal Properties
AimTo Study the Variation in Volume with Pressure for a Sample of Air at Constant Temperature by Plotting Graphs Between P and V, and Between P and 1/V
CBSE · Class 11 · English · Section B Experiment
B-4💧 Mechanical Properties of Fluids
AimTo Determine the Surface Tension of Water by Capillary Rise Method
CBSE · Class 11 · English · Section B Experiment
B-5💧 Mechanical Properties of Fluids
AimTo Determine the Coefficient of Viscosity of a Given Viscous Liquid by Measuring the Terminal Velocity of a Given Spherical Body
CBSE · Class 11 · English · Section B Experiment
B-6🌡️ Thermal Properties of Matter
AimTo Study the Relationship Between the Temperature of a Hot Body and Time by Plotting a Cooling Curve
CBSE · Class 11 · English · Section B Experiment
B-7🌡️ Thermal Properties of Matter
AimTo Determine Specific Heat Capacity of a Given Solid by Method of Mixtures
CBSE · Class 11 · English · Section B Experiment
B-8🔊 Waves
AimTo Study the Relation Between Frequency and Length of a Given Wire Under Constant Tension Using a Sonometer
CBSE · Class 11 · English · Section B Experiment
B-9🔊 Waves
AimTo Study the Relation Between the Length of a Given Wire and Tension for Constant Frequency Using a Sonometer
CBSE · Class 11 · English · Section B Experiment
B-10🔊 Waves
AimTo Find the Speed of Sound in Air at Room Temperature Using a Resonance Tube by Two Resonance Positions
CBSE · Class 11 · English · Section B Experiment
🔍
Koi practical nahi mila
Spelling check kijiye, ya "All" tab aur "All Chapters" chip par click karke dobara try karein.
📊 Physics Practical — Marks Distribution
Board practical kaise divide hota hai, ek nazar me.
| Component | Marks |
|---|---|
| Two experiments — ek Section A se, ek Section B se | 7 + 7 |
| Practical record (experiments + activities) | 5 |
| One activity — kisi bhi section se | 3 |
| Investigatory Project | 3 |
| Viva on experiments, activities & project | 5 |
| Total Practical Marks | 30 |
⚠️ Ye CBSE ka standard practical scheme hai. Marks breakup kabhi-kabhi revise hota hai, isliye apne session ka official CBSE curriculum document ek baar zaroor check kar lein.
❓ Class 11 Physics Practical — FAQs
Section A/B, least count, graph aur viva se jude common sawaal.
Class 11 Physics practical me Section A aur Section B kya hota hai?
CBSE Class 11 Physics ka practical syllabus do hisson me hai. Section A mainly measurement aur mechanics par based hai — vernier callipers, screw gauge, spherometer, beam balance, parallelogram law aur simple pendulum. Section B mainly properties of matter, heat aur waves par based hai — Young's modulus, spring constant, Boyle's law, surface tension, viscosity, cooling curve, specific heat capacity, sonometer aur resonance tube. Board practical me dono sections me se ek-ek experiment aata hai.
Experiment aur Activity me kya farak hai?
Experiment me observation table banani hoti hai, readings leni hoti hain, calculation aur zyadatar graph plot karna hota hai, aur ek numerical result nikalta hai. Activity chhoti hoti hai — ismein mainly observe karna, banana ya compare karna hota hai aur result descriptive hota hai. Board me experiment ke marks zyada hote hain (7+7) aur activity ke kam (3).
Vernier callipers ka least count kaise nikalte hain?
Least count = (ek main scale division ki value) ÷ (vernier scale ke kul divisions). Standard vernier callipers me 1 MSD = 1 mm aur vernier par 10 divisions hote hain, isliye LC = 0.1 mm = 0.01 cm. Final reading = main scale reading + (vernier coinciding division × LC), aur uske baad zero error ka correction lagana zaroori hai.
Screw gauge ka least count aur zero error kya hota hai?
Least count = pitch ÷ circular scale ke kul divisions. Aam screw gauge me pitch 1 mm aur circular scale par 100 divisions hote hain, isliye LC = 0.01 mm. Jaws band karne par agar circular scale ka zero reference line se upar ruke to zero error negative hota hai aur niche chala jaye to positive — usi hisaab se correction jodna ya ghatana padta hai.
Simple pendulum me L–T² graph straight line kyun aata hai?
Time period length ke square root ke proportional hota hai, isliye T² directly L ke proportional ho jata hai. Yahi wajah hai ki L–T graph curve deta hai lekin L–T² graph origin se guzarti ek straight line deta hai, jiske slope se g ki value nikali ja sakti hai. Second's pendulum ka time period 2 second hota hai aur uski effective length lagbhag 1 metre aati hai.
CBSE Class 11 Physics practical kitne marks ka hota hai?
Practical component aam taur par 30 marks ka hota hai — do experiments (7+7), practical record (5), ek activity (3), investigatory project (3) aur viva voce (5). Upar di gayi table me poora breakup hai. Exact distribution har session ke official CBSE curriculum document me rehta hai, isliye apne year ka latest syllabus check kar lein.
Class 11 Physics practical file kaise banayein?
Har experiment ko is order me likhein — Aim → Apparatus Required → Theory & Formula → Diagram → Procedure → Least Count & Zero Error → Observation Table → Calculations → Graph → Result → Precautions → Sources of Error. Diagram aur graph blank ya graph page par pencil se banayein, aur observation table ruled page par. Upar kisi bhi card ko kholkar ready-made format copy kar sakte hain.
Physics practical viva ki taiyari kaise karein?
Har experiment ka aim, formula aur symbols ka meaning, apparatus ka principle, graph ka shape aur 2–3 precautions yaad rakhein. Section A me sawaal zyadatar least count, zero error, significant figures aur pendulum se aate hain; Section B me elasticity, surface tension, viscosity, Newton's law of cooling aur resonance se. Upar diye progress tracker se check karte rahiye kaunse baaki hain.
